Example: documenting UVM

The extension documents the full UVM library end-to-end from its NaturalDocs-commented source — the project’s Phase-2 acceptance target. A real build produces ~5700 documented objects in a few seconds.

This page is generated live from the UVM sources in this repository (fetched by ivpm into packages/uvm). Scroll to Rendered UVM reference for the rendered output.

Configuration

Point the extension at uvm_pkg.sv as the build-unit root, with the UVM source directory on the include path:

extensions = ["sphinx_systemverilog"]

sv_build_units  = ["/path/to/uvm/src/uvm_pkg.sv"]
sv_include_dirs = ["/path/to/uvm/src"]
sv_doc_style    = "naturaldocs"

uvm_pkg.sv `includes the entire library, so a single build unit elaborates all of UVM into one project-wide index.

What you get:

• Inheritance — uvm_object extends uvm_void, uvm_component extends uvm_report_object, etc., with an inheritance diagram.

• Members — extern method prototypes (which UVM uses throughout) are documented with their signatures.

• Groups — UVM Group: headers (Seeding, Identification, …) become labeled subsections.

• Prose — detached // Function -- NODOCS -- name blocks, separated from their prototypes by @uvm-ieee annotations, are associated correctly, with <xref> and ~code~ markup converted.

Documenting the whole library at once

Rather than listing classes by hand, generate the entire UVM API tree with a single whole-tree directive:

.. autosvsummary::
   :packages: uvm_pkg
   :kinds: class

Diagnostics

UVM elaborates with many benign lint-style warnings (width truncation, dangling else, …). These are not surfaced as build warnings; they are counted and reported once at INFO level. Only genuine parse errors are surfaced.

Rendered UVM reference

When the UVM sources are present, the classes below are pulled directly from them (otherwise this section is empty — run ivpm update -a to fetch UVM).

class uvm_object  extends uvm_void

The uvm_object class is the base class for all UVM data and hierarchical classes. Its primary role is to define a set of methods for such common operations as create, copy, compare, print, and record. Classes deriving from uvm_object must implement the pure virtual methods such as create and get_type_name.

function new(string name)

Creates a new uvm_object with the given instance name. If name is not supplied, the object is unnamed.

Seeding

property bit use_uvm_seeding

@uvm-compat provided for compatbility with 1.2

static function get_uvm_seeding()

static function set_uvm_seeding(bit enable)

function reseed()

Calls srandom on the object to reseed the object using the UVM seeding mechanism, which sets the seed based on type name and instance name instead of based on instance position in a thread.

If get_uvm_seeding returns 0, then reseed() does not perform any function.

Identification

function set_name(string name)

Sets the instance name of this object, overwriting any previously given name.

function get_name()

Returns the name of the object, as provided by the name argument in the new constructor or set_name method.

function get_full_name()

Returns the full hierarchical name of this object. The default implementation is the same as get_name, as uvm_objects do not inherently possess hierarchy.

Objects possessing hierarchy, such as uvm_components, override the default implementation. Other objects might be associated with component hierarchy but are not themselves components. For example, <uvm_sequence #(REQ,RSP)> classes are typically associated with a <uvm_sequencer #(REQ,RSP)>. In this case, it is useful to override get_full_name to return the sequencer’s full name concatenated with the sequence’s name. This provides the sequence a full context, which is useful when debugging.

function get_inst_id()

Returns the object’s unique, numeric instance identifier.

static function get_inst_count()

Returns the current value of the instance counter, which represents the total number of uvm_object-based objects that have been allocated in simulation. The instance counter is used to form a unique numeric instance identifier.

static function get_type()

Returns the type-proxy (wrapper) for this object. The uvm_factory’s type-based override and creation methods take arguments of uvm_object_wrapper. This method, if implemented, can be used as convenient means of supplying those arguments.

The default implementation of this method produces an error and returns null. To enable use of this method, a user’s subtype must implement a version that returns the subtype’s wrapper.

For example:

| class cmd extends uvm_object; | typedef uvm_object_registry #(cmd) type_id; | static function type_id get_type(); | return type_id::get(); | endfunction | endclass

Then, to use:

| factory.set_type_override(cmd::get_type(),subcmd::get_type());

This function is implemented by the `uvm_*_utils macros, if employed.

function get_object_type()

Returns the type-proxy (wrapper) for this object. The uvm_factory’s type-based override and creation methods take arguments of uvm_object_wrapper. This method, if implemented, can be used as convenient means of supplying those arguments. This method is the same as the static get_type method, but uses an already allocated object to determine the type-proxy to access (instead of using the static object).

The default implementation of this method does a factory lookup of the proxy using the return value from get_type_name. If the type returned by get_type_name is not registered with the factory, then a null handle is returned.

For example:

| class cmd extends uvm_object; | typedef uvm_object_registry #(cmd) type_id; | static function type_id get_type(); | return type_id::get(); | endfunction | virtual function type_id get_object_type(); | return type_id::get(); | endfunction | endclass

This function is implemented by the `uvm_*_utils macros, if employed.

function get_type_name()

This function returns the type name of the object, which is typically the type identifier enclosed in quotes. It is used for various debugging functions in the library, and it is used by the factory for creating objects.

This function must be defined in every derived class.

A typical implementation is as follows:

| class mytype extends uvm_object; | … | static function string type_name(); return “myType”; endfunction : type_name | | virtual function string get_type_name(); | return type_name; | endfunction

We define the type_name static method to enable access to the type name without need of an object of the class, i.e., to enable access via the scope operator, mytype::type_name.

Creation

function create(string name)

The create method allocates a new object of the same type as this object and returns it via a base uvm_object handle. Every class deriving from uvm_object, directly or indirectly, must implement the create method.

A typical implementation is as follows:

| class mytype extends uvm_object; | … | virtual function uvm_object create(string name=””); | mytype t = new(name); | return t; | endfunction

function clone()

The clone method creates and returns an exact copy of this object.

The default implementation calls create followed by copy. As clone is virtual, derived classes may override this implementation if desired.

Printing

function print(uvm_printer printer)

The print method deep-prints this object’s properties in a format and manner governed by the given printer argument; if the printer argument is not provided, the global uvm_default_printer is used. See uvm_printer for more information on printer output formatting. See also uvm_line_printer, uvm_tree_printer, and uvm_table_printer for details on the pre-defined printer “policies,” or formatters, provided by the UVM.

The print method is not virtual and must not be overloaded. To include custom information in the print and sprint operations, derived classes must override the do_print method and use the provided printer policy class to format the output.

function sprint(uvm_printer printer)

The sprint method works just like the print method, except the output is returned in a string rather than displayed.

The sprint method is not virtual and must not be overloaded. To include additional fields in the print and sprint operation, derived classes must override the do_print method and use the provided printer policy class to format the output. The printer policy will manage all string concatenations and provide the string to sprint to return to the caller.

function do_print(uvm_printer printer)

The do_print method is the user-definable hook called by print and sprint that allows users to customize what gets printed or sprinted beyond the field information provided by the `uvm_field_* macros, <Utility and Field Macros for Components and Objects>.

The printer argument is the policy object that governs the format and content of the output. To ensure correct print and sprint operation, and to ensure a consistent output format, the printer must be used by all do_print implementations. That is, instead of using $display or string concatenations directly, a do_print implementation must call through the printer's API to add information to be printed or sprinted.

An example implementation of do_print is as follows:

| class mytype extends uvm_object; | data_obj data; | int f1; | virtual function void do_print (uvm_printer printer); | super.do_print(printer); | printer.print_field_int(“f1”, f1, $bits(f1), UVM_DEC); | printer.print_object(“data”, data); | endfunction

Then, to print and sprint the object, you could write:

| mytype t = new; | t.print(); | uvm_report_info(“Received”,t.sprint());

See uvm_printer for information about the printer API.

function convert2string()

This virtual function is a user-definable hook, called directly by the user, that allows users to provide object information in the form of a string. Unlike sprint, there is no requirement to use a uvm_printer policy object. As such, the format and content of the output is fully customizable, which may be suitable for applications not requiring the consistent formatting offered by the print/sprint/do_print API.

Fields declared in <Utility Macros> macros (`uvm_field_*), if used, will not automatically appear in calls to convert2string.

An example implementation of convert2string follows.

| class base extends uvm_object; | string field = “foo”; | virtual function string convert2string(); | convert2string = {“base_field=”,field}; | endfunction | endclass | | class obj2 extends uvm_object; | string field = “bar”; | virtual function string convert2string(); | convert2string = {“child_field=”,field}; | endfunction | endclass | | class obj extends base; | int addr = ‘h123; | int data = ‘h456; | bit write = 1; | obj2 child = new; | virtual function string convert2string(); | convert2string = {super.convert2string(), | $sformatf(” write=%0d addr=%8h data=%8h “,write,addr,data), | child.convert2string()}; | endfunction | endclass

Then, to display an object, you could write:

| obj o = new; | uvm_report_info(“BusMaster”,{“Sending:n “,o.convert2string()});

The output will look similar to:

| UVM_INFO @ 0: reporter [BusMaster] Sending: | base_field=foo write=1 addr=00000123 data=00000456 child_field=bar

Recording

function record(uvm_recorder recorder)

The record method deep-records this object’s properties according to an optional recorder policy. The method is not virtual and must not be overloaded. To include additional fields in the record operation, derived classes should override the do_record method.

The optional recorder argument specifies the recording policy, which governs how recording takes place. See uvm_recorder for information.

A simulator’s recording mechanism is vendor-specific. By providing access via a common interface, the uvm_recorder policy provides vendor-independent access to a simulator’s recording capabilities.

function do_record(uvm_recorder recorder)

The do_record method is the user-definable hook called by the record method. A derived class should override this method to include its fields in a record operation.

The recorder argument is policy object for recording this object. A do_record implementation should call the appropriate recorder methods for each of its fields. Vendor-specific recording implementations are encapsulated in the recorder policy, thereby insulating user-code from vendor-specific behavior. See uvm_recorder for more information.

A typical implementation is as follows:

| class mytype extends uvm_object; | data_obj data; | int f1; | function void do_record (uvm_recorder recorder); | recorder.record_field(“f1”, f1, $bits(f1), UVM_DEC); | recorder.record_object(“data”, data); | endfunction

Copying

function copy(uvm_object rhs, uvm_copier copier)

The copy makes this object a copy of the specified object.

The copy method is not virtual and should not be overloaded in derived classes. To copy the fields of a derived class, that class should override the do_copy method.

function do_copy(uvm_object rhs)

The do_copy method is the user-definable hook called by the copy method. A derived class should override this method to include its fields in a copy operation.

A typical implementation is as follows:

| class mytype extends uvm_object; | … | int f1; | function void do_copy (uvm_object rhs); | mytype rhs_; | super.do_copy(rhs); | $cast(rhs_,rhs); | field_1 = rhs_.field_1; | endfunction

The implementation must call super.do_copy, and it must $cast the rhs argument to the derived type before copying.

Comparing

function compare(uvm_object rhs, uvm_comparer comparer)

Deep compares members of this data object with those of the object provided in the rhs (right-hand side) argument, returning 1 on a match, 0 otherwise.

The compare method is not virtual and should not be overloaded in derived classes. To compare the fields of a derived class, that class should override the do_compare method.

The optional comparer argument specifies the comparison policy. It allows you to control some aspects of the comparison operation. It also stores the results of the comparison, such as field-by-field miscompare information and the total number of miscompares. If a compare policy is not provided, then the global uvm_default_comparer policy is used. See uvm_comparer for more information.

function do_compare(uvm_object rhs, uvm_comparer comparer)

The do_compare method is the user-definable hook called by the compare method. A derived class should override this method to include its fields in a compare operation. It should return 1 if the comparison succeeds, 0 otherwise.

A typical implementation is as follows:

| class mytype extends uvm_object; | … | int f1; | virtual function bit do_compare (uvm_object rhs,uvm_comparer comparer); | mytype rhs_; | do_compare = super.do_compare(rhs,comparer); | $cast(rhs_,rhs); | do_compare &= comparer.compare_field_int(“f1”, f1, rhs_.f1); | endfunction

A derived class implementation must call super.do_compare() to ensure its base class’ properties, if any, are included in the comparison. Also, the rhs argument is provided as a generic uvm_object. Thus, you must $cast it to the type of this object before comparing.

The actual comparison should be implemented using the uvm_comparer object rather than direct field-by-field comparison. This enables users of your class to customize how comparisons are performed and how much miscompare information is collected. See uvm_comparer for more details.

Packing

function pack(ref bit$[] bitstream, uvm_packer packer)

function pack_bytes(ref byte unsigned$[] bytestream, uvm_packer packer)

function pack_ints(ref int unsigned$[] intstream, uvm_packer packer)

The pack methods bitwise-concatenate this object’s properties into an array of bits, bytes, or ints. The methods are not virtual and must not be overloaded. To include additional fields in the pack operation, derived classes should override the do_pack method.

The optional packer argument specifies the packing policy, which governs the packing operation. If a packer policy is not provided, the global uvm_default_packer policy is used. See uvm_packer for more information.

The return value is the total number of bits packed into the given array. Use the array’s built-in size method to get the number of bytes or ints consumed during the packing process.

function pack_longints(ref longint unsigned$[] longintstream, uvm_packer packer)

@uvm-ieee 1800.2-2020 auto 5.3.10.1

function do_pack(uvm_packer packer)

The do_pack method is the user-definable hook called by the pack methods. A derived class should override this method to include its fields in a pack operation.

The packer argument is the policy object for packing. The policy object should be used to pack objects.

A typical example of an object packing itself is as follows

| class mysubtype extends mysupertype; | … | shortint myshort; | obj_type myobj; | byte myarray[]; | … | function void do_pack (uvm_packer packer); | super.do_pack(packer); // pack mysupertype properties | packer.pack_field_int(myarray.size(), 32); | foreach (myarray) | packer.pack_field_int(myarray[index], 8); | packer.pack_field_int(myshort, $bits(myshort)); | packer.pack_object(myobj); | endfunction

The implementation must call super.do_pack so that base class properties are packed as well.

If your object contains dynamic data (object, string, queue, dynamic array, or associative array), and you intend to unpack into an equivalent data structure when unpacking, you must include meta-information about the dynamic data when packing as follows.

• For queues, dynamic arrays, or associative arrays, pack the number of elements in the array in the 32 bits immediately before packing individual elements, as shown above.

• For string data types, append a zero byte after packing the string contents.

• For objects, pack 4 bits immediately before packing the object. For null objects, pack 4’b0000. For non-null objects, pack 4’b0001.

When the `uvm_field_* macros are used, <Utility and Field Macros for Components and Objects>, the above meta information is included.

Packing order does not need to match declaration order. However, unpacking order must match packing order.

Unpacking

function unpack(ref bit$[] bitstream, uvm_packer packer)

function unpack_bytes(ref byte unsigned$[] bytestream, uvm_packer packer)

function unpack_ints(ref int unsigned$[] intstream, uvm_packer packer)

The unpack methods extract property values from an array of bits, bytes, or ints. The method of unpacking must exactly correspond to the method of packing. This is assured if (a) the same packer policy is used to pack and unpack, and (b) the order of unpacking is the same as the order of packing used to create the input array.

The unpack methods are fixed (non-virtual) entry points that are directly callable by the user. To include additional fields in the unpack operation, derived classes should override the do_unpack method.

The optional packer argument specifies the packing policy, which governs both the pack and unpack operation. If a packer policy is not provided, then the global uvm_default_packer policy is used. See uvm_packer for more information.

The return value is the actual number of bits unpacked from the given array.

function unpack_longints(ref longint unsigned$[] longintstream, uvm_packer packer)

@uvm-ieee 1800.2-2020 auto 5.3.11.1

function do_unpack(uvm_packer packer)

The do_unpack method is the user-definable hook called by the unpack method. A derived class should override this method to include its fields in an unpack operation.

The packer argument is the policy object for both packing and unpacking. It must be the same packer used to pack the object into bits. Also, do_unpack must unpack fields in the same order in which they were packed. See uvm_packer for more information.

The following implementation corresponds to the example given in do_pack.

| function void do_unpack (uvm_packer packer); | int sz; | super.do_unpack(packer); // unpack super’s properties | sz = packer.unpack_field_int(myarray.size(), 32); | myarray.delete(); | for(int index=0; index<sz; index++) | myarray[index] = packer.unpack_field_int(8); | myshort = packer.unpack_field_int($bits(myshort)); | packer.unpack_object(myobj); | endfunction

If your object contains dynamic data (object, string, queue, dynamic array, or associative array), and you intend to unpack into an equivalent data structure, you must have included meta-information about the dynamic data when it was packed.

• For queues, dynamic arrays, or associative arrays, unpack the number of elements in the array from the 32 bits immediately before unpacking individual elements, as shown above.

• For string data types, unpack into the new string until a null byte is encountered.

• For objects, unpack 4 bits into a byte or int variable. If the value is 0, the target object should be set to null and unpacking continues to the next property, if any. If the least significant bit is 1, then the target object should be allocated and its properties unpacked.

function do_execute_op(uvm_field_op op)

@uvm-ieee 1800.2-2020 auto 5.3.13

Configuration

function set_local(uvm_resource_base rsrc)

@uvm-ieee 1800.2-2020 auto 5.3.12

local function m_pack(inout uvm_packer packer)

**** Internal Methods and Properties *** Do not use directly

local property string m_leaf_name

The print_matches bit causes an informative message to be printed when a field is set using one of the set methods.

function set_int_local(string field_name, uvm_pkg::uvm_bitstream_t value, bit recurse)

@uvm-compat for compatibility with 1.2

function set_string_local(string field_name, string value, bit recurse)

@uvm-compat for compatibility with 1.2

function set_object_local(string field_name, uvm_object value, bit clone, bit recurse)

@uvm-compat for compatibility with 1.2

class uvm_sequence_item  extends uvm_transaction

The base class for user-defined sequence items and also the base class for the uvm_sequence class. The uvm_sequence_item class provides the basic functionality for objects, both sequence items and sequences, to operate in the sequence mechanism.

function new(string name)

The constructor method for uvm_sequence_item.

function get_type_name()

Returns the value given by the string parameter, Tname. This method overrides the method in uvm_object_wrapper.

static function get_type()

Static function that returns the static type handle. The return type is this_type, which is the type of the parameterized class.

function get_object_type()

Returns the type-proxy (wrapper) for this object. The uvm_factory’s type-based override and creation methods take arguments of uvm_object_wrapper. This method, if implemented, can be used as convenient means of supplying those arguments. This method is the same as the static get_type method, but uses an already allocated object to determine the type-proxy to access (instead of using the static object).

The default implementation of this method does a factory lookup of the proxy using the return value from get_type_name. If the type returned by get_type_name is not registered with the factory, then a null handle is returned.

For example:

| class cmd extends uvm_object; | typedef uvm_object_registry #(cmd) type_id; | static function type_id get_type(); | return type_id::get(); | endfunction | virtual function type_id get_object_type(); | return type_id::get(); | endfunction | endclass

This function is implemented by the `uvm_*_utils macros, if employed.

function set_sequence_id(int id)

function get_sequence_id()

private

Get_sequence_id is an internal method that is not intended for user code. The sequence_id is not a simple integer. The get_transaction_id is meant for users to identify specific transactions.

These methods allow access to the sequence_item sequence and transaction IDs. get_transaction_id and set_transaction_id are methods on the uvm_transaction base_class. These IDs are used to identify sequences to the sequencer, to route responses back to the sequence that issued a request, and to uniquely identify transactions.

The sequence_id is assigned automatically by a sequencer when a sequence initiates communication through any sequencer calls (i.e. `uvm_do_*, wait_for_grant). A sequence_id will remain unique for this sequence until it ends or it is killed. However, a single sequence may have multiple valid sequence ids at any point in time. Should a sequence start again after it has ended, it will be given a new unique sequence_id.

The transaction_id is assigned automatically by the sequence each time a transaction is sent to the sequencer with the transaction_id in its default (-1) value. If the user sets the transaction_id to any non-default value, that value will be maintained.

Responses are routed back to this sequences based on sequence_id. The sequence may use the transaction_id to correlate responses with their requests.

function set_item_context(uvm_sequence_base parent_seq, uvm_sequencer_base sequencer)

Set the sequence and sequencer execution context for a sequence item

function set_use_sequence_info(bit value)

function get_use_sequence_info()

These methods are used to set and get the status of the use_sequence_info bit. Use_sequence_info controls whether the sequence information (sequencer, parent_sequence, sequence_id, etc.) is printed, copied, or recorded. When use_sequence_info is the default value of 0, then the sequence information is not used. When use_sequence_info is set to 1, the sequence information will be used in printing and copying.

function set_id_info(uvm_sequence_item item)

Copies the sequence_id and transaction_id from the referenced item into the calling item. This routine should always be used by drivers to initialize responses for future compatibility.

function set_sequencer(uvm_sequencer_base sequencer)

Sets the default sequencer for the sequence to sequencer. It will take effect immediately, so it should not be called while the sequence is actively communicating with the sequencer.

function get_sequencer()

Returns a reference to the default sequencer used by this sequence.

function set_parent_sequence(uvm_sequence_base parent)

Sets the parent sequence of this sequence_item. This is used to identify the source sequence of a sequence_item.

function get_parent_sequence()

Returns a reference to the parent sequence of any sequence on which this method was called. If this is a parent sequence, the method returns null.

function set_depth(int value)

The depth of any sequence is calculated automatically. However, the user may use set_depth to specify the depth of a particular sequence. This method will override the automatically calculated depth, even if it is incorrect.

function get_depth()

Returns the depth of a sequence from its parent. A parent sequence will have a depth of 1, its child will have a depth of 2, and its grandchild will have a depth of 3.

function is_item()

This function may be called on any sequence_item or sequence. It will return 1 for items and 0 for sequences (which derive from this class).

function get_full_name()

Internal method; overrides must follow same naming convention

function get_root_sequence_name()

Provides the name of the root sequence (the top-most parent sequence).

function m_set_p_sequencer()

Internal method

function get_root_sequence()

Provides a reference to the root sequence (the top-most parent sequence).

function get_sequence_path()

Provides a string of names of each sequence in the full hierarchical path. A “.” is used as the separator between each sequence.

Reporting Interface

function uvm_get_report_object()

Returns the nearest uvm_report_object when called. From inside a uvm_component, the method simply returns this.

See also the global version of uvm_get_report_object.

function uvm_report_enabled(int verbosity, uvm_pkg::uvm_severity severity, string id)

Returns 1 if the configured verbosity for this severity/id is greater than or equal to verbosity else returns 0.

See also get_report_verbosity_level and the global version of uvm_report_enabled.

function uvm_report(uvm_pkg::uvm_severity severity, string id, string message, int verbosity, string filename, int line, string context_name, bit report_enabled_checked)

function uvm_report_info(string id, string message, int verbosity, string filename, int line, string context_name, bit report_enabled_checked)

function uvm_report_warning(string id, string message, int verbosity, string filename, int line, string context_name, bit report_enabled_checked)

function uvm_report_error(string id, string message, int verbosity, string filename, int line, string context_name, bit report_enabled_checked)

function uvm_report_fatal(string id, string message, int verbosity, string filename, int line, string context_name, bit report_enabled_checked)

These are the primary reporting methods in the UVM. uvm_sequence_item derived types delegate these functions to their associated sequencer if they have one, or to the global reporter. See uvm_report_object::Reporting for details on the messaging functions.

function uvm_process_report_message(uvm_report_message report_message)

This method takes a preformed uvm_report_message, populates it with the report object and passes it to the report handler for processing. It is expected to be checked for verbosity and populated.

function do_print(uvm_printer printer)

Internal method
